Pulse Amplifier

Model No. AMP02

High amplification pulse amplifier suitable for pulses of 1nsec width.

【Related Contents】
👉Products Line-up of Amplifier

Parts No. (Please consult with your KEYCOM representative for detailed specifications)

Parts No. Frequency Gain dB
(at 700MHz )
Flatness
dB (22.5MHz-1GHz)
Noise
(When the end terminated 50Ω)
Maximum output voltage Size (mm) Power supply
KA-10010LN52N-M-1 100kHz-1GHz 52±3dB 10dB max. 25mVp-p max. 3.5Vmin. 60(L)×25.5(W)×11(H) 10-20VDC,
100mA max.
KA-10010LN52N-M-2 100kHz-1GHz 52±3dB 3dB max. 25mVp-p max. 3.5Vmin. 50(L)×20.0(W)×8(H) 7.25±0.10VDC,
100mA max.
KA-10010LN64N-M-1 100kHz-1GHz 64±0.5dB 8dB max. 60mVp-p max. 3.5Vmin. 60(L)×22.0(W)×14(H) 7.25±0.10VDC,
350mA max.
