Bias-TEE For Room Temperature
3A Type

Model No. BYT01 : KDC-H500M6G-01

This is the first compact wideband Bias Tee to achieve an input current of 3000 mA at the DC port.
The lead time also is shorter than before.

Specifications

Part No.	KDC-H500M6G-01
Characteristic impedance [Ω]	50
Minimum frequency (-3dB)[Hz]	490M
Maximum frequency[Hz]	5.76G
DC electric strength (max) [V]	25
DC Maximum supply current [mA]	3000
Amount of reflection attenuation (max) [dB]	-10
Connector	SMA(f),(f)
Size [mm] (not included connector areas)	20(W) x 33.4(L) x 11.5(H)mm
